Click lens for actual comparison images.
The lens shade will cut an unwanted light beam, and it prevents flare and
ghost image effect considerably.
|
|
HDP-7700ES High Definition
Super-Telephoto conversion Lens 3.0x
Finally, we are able to introduce an ultimate telephoto lens of 3.0 times high powered yet constructed in compact measurements of 92mm length (without Lens Shade) x 58mm outside diameter (at the largest). Thanks to the State-of-the-art lens designing formula developed here in Tokyo Lab, the new 3-group/5-element construction of high index optical glasses reached up to a high image standard of 220 lines/mm resolution power at center (MTF30%) with three times high powered telephoto magnification. It never reached before.
The Lens Shade and 5-adapter rings come with the lens as a standard accessory.
With the HDP-7700ES lens attached, there will be no influence on F number
of the master lens. |
Magnification: Nominal 3.0x
Actual 3.0x/Diagonal,
3.0x/Horizontal
Lens construction: 3G/5E Optical coated glass elements
Minimum focusing distance: 10m/6m(Tele-macro mode)
Effective zooming without vignetting: 9x - 10x zoom
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 92 x 58mm/218g(7.68oz)
Accessories included: LS-055 Lens Shade, Lens caps, Lens pouch,
5-adapter rings 27mm/30mm/30.5mm/34mm/43mm filter size.
Specifications |
Comparison movie taken with the HDP-7700ES on
or without at the same distance
(16:9 Wide mode - Taken with SONY HDR-HC7 HDVcam）
 |
| PAGE TOP |

|
 Click camera for actual comparison images.
HD-2200PRO-LE+(Plus)(Black model)
Weight: 37g.(1.3oz)
 |
|
HD-2205PRO/HD-2200PRO-LE+(Black model)
High Definition
2.2x Telephoto Conversion Lens
The model HD-2205PRO High-Definition Super Telephoto Conversion lens is
made of the hi-index coated optical glass elements with new concept of
lens designing using two-group/four-element lens formula. This new concept
of lens designing made it possible to achieve an amazing high definition
Telephoto lens of the 200 lines/mm resolution power at center (MTF30%).
Model RA3730 adapter ring(Included) is required for use with the HD-2205PRO + HC3, UX1, SR1 camera.
* 4:3 Tape recording mode.
Specifications
The lens shade will cut an unwanted light beam, and it prevents flare and
ghost image effect considerably. |
Magnification: Nominal 2.2x
Actual 2.17x/Diagonal, 2.17x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 4m/2m(tele macro mode)
Effective zooming without vignetting: 6x - 10x zoom
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 76 x 59mm/105g(3.7oz)
Accessories included: LS-055 Lens shade, Lens caps, Lens pouch, 5-adapter rings 27mm/30mm/30.5mm/34mm/43mm filter size.
16:9 mode max. telephoto: No vignetting in (under scanning) mode and still image mode
4:3 mode max. telephoto: No vignetting in (under scanning) mode and still image mode
LS-055 Lens shade is included with HD-2205PRO and HD-2200PRO-LE+(Plus).
|
| PAGE TOP |

|
Click camera for actual comparison images.
|
|
HD-5050PRO/HD-5050PRO-LE(Black version)
High Definition
0.5x Wideangle Conversion Lens
The model HD-5050PRO/HD-5050PRO-LE Super Wideangle conversion lens is designed to broaden the angle of view, including 100% more area in the picture, when attached to the lens of HDR-HC3, HDR-UX1, HDR-SR1 High Definition camcorders. Its compatible with the whole zoom area and stays in focus.
The HD-5050PRO/HD-5050PRO-LE are made of the high-index optical glass elements with new
concept of lens designing using three-group/four-element lens formula.
This new concept in designing the lens made it possible to achieve an amazing
high definition wideangle lens of the 600 lines/mm resolution power at center (MTF30%).
Specifications
(Both HD-5050PRO and HD-5050PRO-LE are the same lens.)
Model RA3730 adapter ring(Included) is required for use with the HD-5050PRO
+ HC3, UX1, SR1 camera.
|
Magnification: Nominal 0.5x
Actual 0.5x/Diagonal,0.53x/Horizontal
Lens construction: 3G/4E Optical coated glass elements
Effective zooming with conversion lens on: Full(1x - 10x) zoom
Front filter size: 62mm
Mounting threads: 37mm
Size/Weight: 40 x 66mm/110g(3.9oz)
Accessories included: Lens caps, Lens case,
6-adapter rings 27mm/30mm/30.5mm/34mm/37mm/43mm filter
size.
16:9 mode max. Wideangle: No vignetting in (under scanning) mode and still image mode
4:3 mode max. Wideangle: No vignetting in (under scanning) mode it shows vignetting(darkening corners of image) in 4:3 still mode
|
| PAGE TOP |

|
Click camera for actual comparison images.
 The lens shade will cut an unwanted light beam, and it prevents flare and ghost image effect considerably.
(Model LS-03W is included in RAYNOX LS-03W-K
Lens Shade Mask Kit which is sold separately.)
|
|
HD-3035PRO/HD-3032PRO High Definition
0.3x Semi-Fisheye Conversion Lens
The model HD-3035PRO/HD-3032PRO Semi-Fish Eye conversion lens is designed to broaden
the angle of view, including 180% more area in the picture, when attached
to the lens of HDR-HC3, HDR-UX1, HDR-SR1 High Definition Camcorders.
The HD-3035PRO/HD-3032PRO has achieved an amazing high definition standard of 520 lines/mm resolution power at center (MTF30%) in the Semi-Fish Eye formula.
Specifications
(There is no quality difference between HD-3035PRO and HD-3032PRO lens.)
Model RA3730 adapter ring(Included) is required for use with the HD-3035PRO/HD-3032PRO
+ HC3, UX1, SR1 camera.
|
Magnification: Nominal 0.3x
Actual 0.34x/Diagonal, 0.44x/Horizontal(4:3mode)
Lens construction: 2G/2E Optical coated glass elements
Effective zooming with conversion lens on: 1x - 6x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 45 x 70mm/143g(5.0oz)
Accessories included with HD-3035PRO : LS-03W Lens shade mask, Lens caps, Lens case, 5-adapter rings
27mm/30mm/30.5mm/37mm/34mm/43mm filter size.
Accessories included with HD-3032PRO : Lens caps, Lens case, 5-adapter rings
27mm/30mm/30.5mm/37mm/34mm/43mm filter size.
16:9 mode max. Wideangle: No vignetting in (under scanning) mode and still image mode
4:3 mode max. Wideangle: No vignetting in (under scanning) mode it shows vignetting(darkening corners of image) in 4:3 still mode
LS-03W Lens shade mask is included with HD-3035PRO.
LS-03W Lens shade mask is Not included with HD-3032PRO. |
| PAGE TOP |
  |
Click camera for actual comparison images.
|
|
DVM-700 Wideangle Conversion Lens 0.7x
It is made of metal barrel with mounting threads of 30mm, and the lens
comes with 2adapter rings, 27mm and 30.5mm. It could be used as permanently
attached for convenient wide coverage video shooting.
30mm mounting threads for direct mounting on the HC3, UX1, SR1 High Definition
cameras. |
Magnification: Nominal 0.7x
Actual 0.66x/Diagonal, 0.7x/Horizontal(4:3mode)
Lens construction: 2G/2E Optical coated glass elements
Effective zooming with conversion lens on: 1x - 10x zoom
Front filter size: None
Mounting threads: 30mm
Size/Weight: 22 x 43mm/40g(5.0oz)
Accessories included : Lens caps, Lens case, 2-adapter rings
27mm/30.5mm filter size.
16:9 mode max. Wideangle: No vignetting in (under scanning) mode and still image mode
4:3 mode max. Wideangle: No vignetting in (under scanning) mode it shows vignetting(darkening corners of image) in 4:3 still mode
Production discontinued in Feb-2009. |
| PAGE TOP |
  |
Click camera for actual comparison images. |
|
MSN-202 MacroScan Close-up Lens
The combination of MSN-202 and HDR-HC3, UX1, SR1 display panel makes it
easy to capture a tiny object from the distance of 30mm (TELE MACRO mode)
to the object at maximum telephoto position.
Model RA3730 adapter ring (Sold separately) is required for use with the
MSN-202 + HC3, UX1, SR1 camera.
|
Magnification: 8 times more of the camera's maximum wide macro image size.
Lens construction: 3G/4E Optical coated glass elements
Image size: 3mm width(16:9 tape mode), 4mm width(16:9 still image mode)
Effective zooming without vignetting: 2x - 10x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 22 x 42mm/60g(2.1oz)
Accessories included : Lens caps, Lens case, Universal adapter UAC3500.
RA3730 adapter ring is Not Included. |
| PAGE TOP |
 |
Click camera for actual comparison images. |
|
MSN-505 Super MacroScan Close-up Lens
With MSN-500 Super Macro lens attached, the camera captures an intricate
tiny object like 2.2mm width for a frame-filling enlarged close-up image
from the distance of 18mm to the object at the maximum telephoto position.(Tele
Macro mode)
Model RA3730 adapter ring (Sold separately) is required for use with the MSN-505 + HC3, UX1, SR1 camera.
|
Magnification: 11 times more of the camera's maximum wide macro image size.
Lens construction: 3G/4E Optical coated glass elements
Image size: 2.2mm width(16:9 tape mode), 3mm width(16:9 still image mode)
Effective zooming without vignetting: 3x - 10x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 26 x 42mm/86g(3oz)
Accessories included : Lens caps, Lens case, Universal adapter UAC3500.
RA3730 adapter ring is Not Included. |
| PAGE TOP |
  |
|
|
PFR-030MC Lens Protector Filter for HC3, UX1 & SR1
The filter is designed to protect your valuable HDR-HC3, HDR-UX1, HDR-SR1
High Definition Camcorder lens from air pollution or scratches. The multi-layer
coated surfaces will help maintain the original optical performance of
your camera.
|
Thread size: 30mm Pitch0.75
Coatings: Multi-Layer Coated.
Internal video light/Flash may not work with PFR-030MC is attached. |
